Are you looking for a high-quality, high-quality, and affordable truss to meet your performance or party needs?
Wuxi Shengyixin Metal Products Co., Ltd. is located in Wuxi City, Jiangsu Province. It is a large-scale production comprehensive enterprise specializing in stage trusses. Shengyixin takes excellent quality, exquisite craftsmanship, and customer satisfaction as its ultimate goal, allowing customers to receive quality and safety assurance while choosing Shengyixin.
All products with regular specifications are available for direct sales from manufacturers, wholesale and retail, while special specifications can be customized.The trusses sold by Sheng Yixin can definitely make your activities more diverse.
1.improved precision
2.Improved efficiency.
3.Enhanced reliability
4.Custom stages can help you reduce maintenance and replacement expenses over time, resulting in significant cost savings.
CS4060
Section: Square400*600mm Main tube: 50*3.0mmBraces: 50*2.0mm | Inelined tube: 25*2.0mm Length: 0.5/1/2/3/4m Material： Aluminum6082-T6 | ||||||||
| Span(m) | 4m | 6m | 8m | 10m | 12m | 14m | 16m | 18m | 20m |
| (kg/m) | 700 | 430 | 270 | 187 | 130 | 92 | 68 | 50 | 30 |
| (mm) | 5 | 12 | 33 | 54 | 80 | 102 | 151 | 170 | 203 |
| (kg) | 2350 | 1580 | 1300 | 1150 | 850 | 670 | 565 | 500 | 400 |
| (mm) | 11 | 23 | 41 | 65 | 79 | 103 | 138 | 172 | 215 |
BS4060
Section: Square400*600mm Main tube: 50*3.0mmBraces: 50*2.0mm | Inelined tube: 30*2.0mm Length: 0.5/1/2/3/4m Material： Aluminum6061-T6 | |||||||
| Span(m) | 4m | 6m | 8m | 10m | 12m | 14m | 16m | 18m |
| (kg/m) | 625 | 370 | 230 | 130 | 70 | 50 | 37 | 20 |
| (mm) | 12 | 33 | 54 | 80 | 102 | 151 | 370 | 570 |
| (kg) | 1800 | 1200 | 700 | 650 | 450 | 300 | 250 | 200 |
| (mm) | 23 | 41 | 65 | 79 | 103 | 138 | 164 | 188 |
BS30
| Section: Square400*600mm Main tube: 50*3.0mm Braces: 50*2.0mm | Inelined tube: 30*2.0mm Length: 0.5/1/2/3/4m Material： Aluminum6061-T6 | |||||||
| Span(m) | 4m | 6m | 8m | 10m | 12m | 14m | 16m | 18m |
| (kg/m) | 625 | 370 | 230 | 130 | 70 | 50 | 37 | 20 |
| (mm) | 12 | 33 | 54 | 80 | 102 | 151 | 370 | 570 |
| (kg) | 1800 | 1200 | 700 | 650 | 450 | 300 | 250 | 200 |
| (mm) | 23 | 41 | 65 | 79 | 103 | 138 | 164 | 188 |
BS40
Section:Square: 400*400mm Main tube: 50*3.0mm Braces: 30*2.0mm | Inelined tube: 25*2.0mm Length: 0.5/1/2/3/4m Material： Aluminum6061-T6 | |||||||
| Span(m) | 2m | 3m | 4m | 5m | 6m | 8m | 10m | 12m |
| (kg/m) | 1560 | 860 | 500 | 280 | 150 | 80 | 50 | 28 |
| (mm) | 6 | 13 | 22 | 41 | 65 | 98 | 136 | 151 |
| (kg) | 1800 | 1600 | 1200 | 750 | 450 | 300 | 200 | 100 |
| (mm) | 11 | 18 | 34 | 58 | 83 | 90 | 115 | 129 |
